商品描述：
编号：X312010-3上架/更新：2019-11-06/2019-11-21
技术参数：
| 螺旋桨（英寸） | 电压 （V） | 电流（A） | 拉力 （gf） | 功率（W） | 效率 （g/W） | RPM | 全油门负载温度 |
|---|---|---|---|---|---|---|---|
| APC12*8 | 11.1 | 5.6 | 500 | 62.16 | 8.04 | 4220 | 88℃ 10min |
| 9.6 | 750 | 106.56 | 7.04 | 5160 | |||
| 14.3 | 1000 | 158.73 | 6.30 | 5960 | |||
| 20.1 | 1250 | 223.11 | 5.60 | 6490 | |||
| 26.4 | 1500 | 293.04 | 5.12 | 7120 | |||
| 33.2 | 1750 | 368.52 | 4.75 | 7725 | |||
| 42.2 | 2000 | 468.42 | 4.27 | 8090 | |||
| 55.1 | 2350 | 611.61 | 3.84 | 8796 | |||
| 12.5 | 5 | 500 | 62.5 | 8.00 | 4235 | ||
| 8.65 | 750 | 108.125 | 6.94 | 5169 | |||
| 13 | 1000 | 162.5 | 6.15 | 5911 | |||
| 17.8 | 1250 | 222.5 | 5.62 | 6450 | |||
| 23.5 | 1500 | 293.75 | 5.11 | 7143 | |||
| 29.8 | 1750 | 372.5 | 4.70 | 7745 | |||
| 37.3 | 2000 | 466.25 | 4.29 | 8090 | |||
| 46.4 | 2250 | 580 | 3.88 | 8635 | |||
| 56 | 2500 | 700 | 3.57 | 9256 | |||
| 66.4 | 2720 | 830 | 3.28 | 9450 | |||
| APC12*6 | 11.1 | 5.5 | 500 | 61.05 | 8.19 | 4635 | 78℃ 10min |
| 9.1 | 750 | 101.01 | 7.43 | 5995 | |||
| 13.5 | 1000 | 149.85 | 6.67 | 6450 | |||
| 18.5 | 1250 | 205.35 | 6.09 | 7200 | |||
| 24.2 | 1500 | 268.62 | 5.58 | 7749 | |||
| 30.8 | 1750 | 341.88 | 5.12 | 8265 | |||
| 38.7 | 2000 | 429.57 | 4.66 | 8860 | |||
| 49.8 | 2390 | 552.78 | 4.32 | 9341 | |||
| 12.5 | 4.9 | 500 | 61.25 | 8.16 | 4695 | ||
| 8.3 | 750 | 103.75 | 7.23 | 5680 | |||
| 12.3 | 1000 | 153.75 | 6.50 | 6459 | |||
| 16.7 | 1250 | 208.75 | 5.99 | 7169 | |||
| 21.8 | 1500 | 272.5 | 5.50 | 7750 | |||
| 27.5 | 1750 | 343.75 | 5.09 | 8223 | |||
| 34.3 | 2000 | 428.75 | 4.66 | 8860 | |||
| 41.7 | 2250 | 521.25 | 4.32 | 9350 | |||
| 50.1 | 2500 | 626.25 | 3.99 | 9780 | |||
| 60.5 | 2840 | 756.25 | 3.76 | 10100 | |||
| APC13*6.5 | 11.1 | 5.1 | 500 | 56.61 | 8.83 | 3975 | 70℃ 10min |
| 8.8 | 750 | 97.68 | 7.68 | 4830 | |||
| 13.1 | 1000 | 145.41 | 6.88 | 5527 | |||
| 18.1 | 1250 | 200.91 | 6.22 | 6150 | |||
| 23.7 | 1500 | 263.07 | 5.70 | 6666 | |||
| 30.3 | 1750 | 336.33 | 5.20 | 7200 | |||
| 37.5 | 2000 | 416.25 | 4.80 | 7666 | |||
| 46.1 | 2250 | 511.71 | 4.40 | 8120 | |||
| 60 | 2652 | 666 | 3.98 | 8554 | |||
| APC13*8 | 11.1 | 5.2 | 500 | 57.72 | 8.66 | 3750 | 75℃ 10min |
| 9.1 | 750 | 101.01 | 7.43 | 4565 | |||
| 13.5 | 1000 | 149.85 | 6.67 | 5189 | |||
| 18.7 | 1250 | 207.57 | 6.02 | 5777 | |||
| 24.5 | 1500 | 271.95 | 5.52 | 6260 | |||
| 31.5 | 1750 | 349.65 | 5.01 | 6850 | |||
| 39.3 | 2000 | 436.23 | 4.58 | 7338 | |||
| 48 | 2250 | 532.8 | 4.22 | 7790 | |||
| 63.2 | 2660 | 701.52 | 3.79 | 8230 |
| 定子外径 | 31mm | 转子直径 | 37.7mm |
|---|---|---|---|
| 定子厚度 | 20mm | 电机长度（不含轴长） | 42mm |
| 定子槽数 | 12 | 支持锂电节数 | 3-4S |
| 转子极数 | 14 | 建议使用电调 | 60-80A |
| 电机KV值 | 1025 | 推荐螺旋桨规格 | APC12*8/APC12*6/APC13*6.5/APC13*8 |
| 空载电流 | 2.1A/10V | 适用特技机重量 | 1400g-1700g (3S APC13*6.5\APC12*6\APC12*8) (4S APC11*5.5\APC11*7\APC11*8) |
| 电机电阻 | 16mΩ | 适用3D机重量 | 1100g-1400g (3S APC13*6.5\APC13*8) |
| 最大连续电流 | 75A/30s | ||
| 最大连续功率 | 1100W | ||
| 重量 | 158g |
所含附件：
包含:1 x X3120 1025kv
1 x 配件包
